Copyright 2022 Fi rstech , LLC. “Are you not entertained…?” Page
8
Universal Security Control Module
Install.myfirstech.com
CM2500
Master
Guide
2 Flash
Door Input
3 Flash
Shock stage 1
4 Flash
Shock stage 2
5 Flash
Tilt
6 Flash
Ignition on
7 Flash
Hood Input
8 Flash
Trunk Input
9 Flash
AUX sensor stage 1
10 Flash
AUX sensor stage 2
1. KP2 Keyless Entry window sensor: Unlock/Disarm
Arm/Lock functions do not require programming, however, to unlock/disarm your vehicle you must
program a 4-6 digit passcode (numbers 1 through 6 only) using the instructions below: Note: check
feature 3-16 to make sure it is set to the desired function
STEP 1: Connect KP2 sensor using the KP to Data Adapter included with KP2 sensor to the
GRAY data port on the CM900AS
STEP 2: Make sure feature 4-10 is set to option 3 for “KP2 support” NOTE: If there is also a
Drone module being used, set option 3-07 to option 2 for Drone compatibility using
the Black UART port, and connect Drone module there.
STEP 3: Disarm/unlock the alarm (remote must be programmed first) and choose a 4-6 digit code.
You cannot have zeros.
STEP 4: Turn ignition to the ‘ON’ position and leave driver’s door open. (Door Input must be
connected)
STEP 5: Hold your finger over the “Lock” icon for 3 seconds.
STEP 6: When the siren chirps and LED flash, momentarily place your finger over the first number of
your 4-6 digit code. The siren should chirp quickly indicating the number has been accepted.
STEP 7: Repeat Step 6 until all four - six digits are set. You will get 1 siren chirp and 1 parking light
flash.
Repeat Steps 3 - 6 if you get 3 chirps and light flashes. Your KP2 is now programmed.
Arm/Lock
Hold the Lock Icon for 2.5 seconds to lock/arm the system.
