Universal Security Control Module
Install.myfirstech.com
CM2500
Master
Guide
S-#4
Special Option group 3 Setting Value
Programmable Input channel Options
1
PIC #1 (Default: (-) Door Input (-) Door Input [1] (N/C) Door Input [6] (-) Closed Loop Input [11]
2
PIC #2 (Default: (-) Hood Input (-) Hood Input [2] (N/C) Hood Input [7] (-) Key Sense Input [12]
3
PIC #3 (Default: (-) Pre-Warn Input (-) Pre-Warn Input [3] (N/C) Trunk Input [8]
(-) Ign, Trunk, Shock, Bypass
Input [13]
4
PIC #4 (Default: (-) Trigger Input
(-) Instant Trigger Input
[4]
(-) Arm Input [9]
(-) 2nd Closed Loop Input
[14]
5
PIC #5: (-) Trunk Input (-) Trunk Input [5] (-) Disarm Input [10] (-) Valet Input [ 15 ]
Feature Option Descriptions
FO = Feature Option
1-01 Door Lock/Unlock output Pulse Duration:
FO1 - 0.8 seconds: (-) Negative lock and unlock output time.
FO2 - 2.5 seconds: (-) Negative lock and unlock output time.
FO3 - 0.125 seconds: (-) Negative lock and unlock output time. This option may be helpful
when using lock/unlock to arm/disarm vehicles that may roll windows down with factory
Arm/Disarm wires when the standard output is too long.
FO4- 3.5 seconds: (-) Negative lock and unlock output time.
1-02 Double Pulse Unlock:
FO1 - Off: (default)
FO2 - Unlock: This option will provide a double pulse output only for unlock each time the
CM2500 executes the unlock command. (Length of output time will be based on feature 1-01
option settings.)
FO3 - Lock: This option will provide a double pulse lock output only for lock each time the
CM2500 executes the lock command. (Length of output time will be based on feature 1-01
option settings.)
FO4 - Lock and unlock: This option will provide a double pulse lock output for both lock and
unlock each time the CM2500 executes lock or unlock commands. (Length of output time will
be based on feature 1-01 option settings.)
