1-03 Driver’s Priority Unlock:
FO1 - Off: (default)
FO2 - On: This feature will allow the user to unlock the driver’s door first. If the unlock button
is pressed again within 4 seconds, the other doors will unlock. The driver’s door unlock must be
isolated from the other doors and use the blue (-) unlock. The Orange/Black (-) 2nd unlock is
used to provide unlock output to unlock all other doors.
1-04 Ignition Controlled Locks (DRIVE LOCK): When FO 1 or 2 are selected, the user can activate
the “drive lock” or ignition-controlled door locking feature using a Firstech remote or Drone.
(Please check specific remote user ’s manual for steps to activate Drive lock.)
FO1 - On w/ Foot brake: This option (when activated with the Firstech remote or Drone) will
provide a door lock output when the ignition is turned on and (+) 12 volts is applied to the foot
brake input wire CN4 PIN 6, or over data (feature 1-14 MUST BE SET TO OPTION 2 “Foot
brake input”). There will be an unlock output as soon as ignition is turned off.
FO2 - On: This option (when activated with the Firstech remote or Drone) will provide a door
lock output 30seconds after the ignition is turned on. There will be an unlock output as soon as
ignition is turned off.
FO3 - OFF: This option will disable the drive lock feature.
1-05 Siren Duration: this feature changes the duration of the siren during full alarm.
FO1 - 30 seconds: this option will provide 30 seconds of output (+) on the siren wire (brown
CN4)
during full alarm.
FO2 - 60 seconds: this option will provide 60 seconds of output (+) on the siren wire (brown
CN4)
during full alarm.
FO3 - 120 seconds: this option will provide 120 seconds of output (+) on the siren wire (brown
CN4) during full alarm.
FO4 - Chirps for 20 seconds: this option will provide 20 seconds of pulsed output (+) on the
siren wire (brown CN4) during full alarm.
1-06 Confirmation chirps: This feature will allow the user to select a shorter siren or horn output time
to simulate a quieter arm/disarm/. output.
FO1 - 30mS: This is a 30 milliseconds siren output with arm, disarm, and . confirmation chirps.
It will produce a “medium” volume sound. (Softer than the standard 60mS output)
FO2 - 15mS: This is a 15-millisecond siren output with arm, disarm, and . confirmation chirps.
It will produce a “short” or quiet volume of sound. (Significantly softer than the standard 60mS
output)
FO3 - 60mS: This is a standard 60 millisecond siren output with arm, disarm, and confirmation
chirps.
