FO2 – Secure Start (N/C) Normally Closed: (-)250mA output on when alarm event has been
triggered. (see feature 3-05 for description and timing options)
FO3 – Secure Start (N/O) Normally Open: (-)250mA output upon disarm for the predetermined
time based on feature 3-04 option settings. (see feature 3-04 for output description and timing
options)
3-07 Black UART data port: Provides additional data communication protocol options.
FO1 – Idatalink 2-WAY support: This option allows the CM2500A to communicate with an ADS
ALCA module with full 2way communication. It can also be used to update the CM2500 firmware.
FO2 – Drone: This option allows the CM2500 support a Drone mobile device using full 2-way
Drone protocol.
Special Option Group 1
AUX 1 Output Timing: This feature will be displayed as AU1 on an OP500 programmer and
can be set between 1 - 99 seconds for AUX 1 output timing.
AUX 2 Output Timing: This feature will be displayed as AU2 on an OP500 programmer and
can be set between 1 - 99 seconds for AUX 2 output timing.
AUX 3 Output Timing: This feature will be displayed as AU3 on an OP500 programmer and
can be set between 1 - 99 seconds for AUX 3 output timing.
AUX 4 Output Timing: This feature will be displayed as AU4 on an OP500 programmer and
can be set between 1 - 99 seconds for AUX 4 output timing.
Special Option Group 2
This option group allows the onboard relay to be activated with a function that can be selected
from the setting values listed below. Once the setting value is set, the relay will operate as a
normal single pole double throw relay connecting PIN 87(white wire) to the common PIN
30(white/black wire) which is also separating the common wire PIN 30(white/black wire) from
PIN 87a(white/red).
PRC 1 - (default setting) Parking light activation. This setting will energize the on-board relay
each time the parking light output is generated. In order to provide a (+) park light output you
must connect PIN 87(white wire) to B(+) constant, and then connect PIN 30(white/black) to the
vehicle parking light circuit. Please see the list of additional setting values that can be used to
activate the relay.
SV0 - default setting
SV1 - Parking light: will activate relay with each parking light flash
SV2 - Horn: will activate the relay each time the horn honk output is used
SV3 - Lock: will activate the relay with each lock command
SV4 - Unlock: will activate the relay with each unlock command
SV5 - Priority Unlock: will activate the relay with the priority unlock (2
nd
unlock command)
