Universal Security Control Module
Install.myfirstech.com
CM2500
Master
Guide
-The (-)NEG Valet Mode Input will need to be enabled to enter/exit Valet mode when using the
N/O Secure Start function. The open PTS button will not allow the vehicle to go to ignition on
position.
-NOTE: WE strongly recommend disabling the “OEM control of aftermarket security” function
when using an Idatalink interface with CM. This will significantly increase the security of the
vehicle.
FO1 – OFF
FO2 – 2 min: once the system is disarmed/unlocked the PTS button will be fully functional for 2
minutes. IF the timer runs out the user must disarm/unlock again.
FO3 – 4 min: once the system is disarmed/unlocked the PTS button will be fully functional for 4
minutes. IF the timer runs out the user must disarm/unlock again.
FO4 – 10 min (PROG 1-10 min): once the system is disarmed/unlocked the PTS button will be
fully functional for 10 minutes. IF the timer runs out the user must disarm/unlock again. When
set to option 4 you may use an OP500 updated with OP500 v .36 (available for download at
Firstechdata.com) to change the timer between 1 and 10 minutes using 1-minute increments.
3-05 Normally Closed (N/C) Secure Start output Timer: The N/C Secure Start feature will provide an
output from Blue wire (PIN 9) set to Secure Start N/O (feature 3-06 option 2). This output will be
active for the period of time selected by one of the options below, once the alarm is triggered. It is
designed to be used with our FTI-SPTS (secure Push To Start) vehicle disable T harnesses
IT CAN ALSO BE USED AS A N/O STARTER DISABLE with an FT-ELOCK
When used with the vehicle disable harness, it will disable the PTS button ONLY WHEN THE
ALARM IS TRIGGERED, all other times there will be no output, and the PTS button will function
normally.
-During an alarm event the N/C will disable the PTS button for the selected time to make sure any
additional attempts to “hack” or force start the vehicle will not work even after the siren output times
out. Once the CM is unlocked/disarmed the N/C output will no longer function making the PTS
button operate normally. IF the user needs to disable the N/C Secure Start Output completely they
will need to enter valet mode.
FO1 – OFF
FO2 – 1 min: This will activate the N/C Secure Start output, disabling the PTS button the exact time
of an alarm event and continue to provide output for up to 1 minute or until system is disarmed.
FO3 – 2 min: This will activate the N/C Secure Start output, disabling the PTS button the exact time
of an alarm event and continue to provide output for up to 2 minutes or until system is disarmed.
FO4 – 4 min: This will activate the N/C Secure Start output, disabling the PTS button at the exact
time of an alarm event and continue to provide output for up to 4 minutes or until system is
disarmed.
3-06 Starter Kill Output (Blue wire PIN 9): The Ground While Armed (GWA) is also the starter kill
output which will provide a (-)250mA output once the CM has been armed (see options 2 and 3
for alternate output functions). It can be wired to a standard relay or FT-ELOCK to activate a
starter kill when the alarm is triggered. Please see features 3-04 and 3-05 for options 2 and 3
function descriptions.
FO1 – GWA (Starter Kill): (-)250mA output while armed
