Universal Security Control Module
Install.myfirstech.com
CM2500
Master
Guide
3-01 Gray Port: This feature will determine the function support of the Gray Port.
FO1 - Drone: (default) This option will allow the gray UART port to support the Drone
function.
FO2 - KP2: This option will allow the gray UART port to support KP2 (keyless window sensor)
function. In case of KP2 and Drone, the black UART data port may be used for DRONE.
FO3 – 1WAY RFID EZGO II: This option will allow the gray UART port to be used with the
EZGO II RFID antenna. IT will require the RF to DATA adapter connected to a standard
antenna cable, Remote programming sequence is the same as using the RF port.
3-02 KP2 LED Flash: (Keyless entry window Sensor) this feature allows to disable the KP2 LED
flash when armed.
FO1 - While Armed: This option enables the KP2 LED flash while armed.
FO2 - OFF While Armed: This option disables the KP2 LED flashing while armed.
3-03 KP2 Sensitivity: This feature will allow the sensitivity for the KP2 keyless entry window sensor
to be adjusted to suit the conditions.
FO1 - Normal (default): This will be the standard sensitivity setting.
FO2 - High: This option is the most sensitive sensor setting.
FO3 - Low: This option will be lower sensitivity than the default standard setting.
FO4 - Lowest: This option will decrease the sensor sensitivity to its lowest setting.
3-04 Normally Open (N/O) Secure Start Output Timer: Secure Start feature will provide an output
from the Blue wire (PIN 9) set to Secure Start N/O (feature 3-06 option 3). This output will be
active for the time selected by one of the options below. It is designed to be used with our FTI SPTS
(secure Push To Start) vehicle disable T harnesses. IT CAN ALSO BE USED AS A N/O STARTER
DISABLE with an FT-ELOCK
When used with the vehicle disable harness it will disable the PTS button until the driver is ready to
use it. NOTE: The Vehicle will not be able to go to ignition on until the system is
disarmed/unlocked
Once the CM is unlocked/disarmed the N/O output will energize the SPTS harness making the PTS
button available for use for the preselected time, or until the CM is armed/locked. Once Ignition on
is detected the output will remain latched until Ignition has been turned off and the preselected
time has expired or the system has been armed/lock using a Firstech remote, Drone, or KP
sensor/
-NOTE: When using the N/O option be sure to select a timed output that will be most
convenient for your customer. IF the timer runs out, they MUST disarm/unlock again to re-
activate the Secure Start Output.
-IF the user needs to disable the N/O secure start output for some reason, you can put the CM
into Vale Mode. While in Valet mode the Secure Start Output will activate any time a door is
opened, (or when disarmed/unlocked) allowing the PTS button to function normally.
