1
FOLLOW THE INSTALLATION SEQUENCE RELEVANT TO YOUR CABINETRY
1 SAFETY AND WARNINGS
2 COMPONENTS LIST
3 PRODUCT AND CAVITY DIMENSIONS
4 DOOR PANEL DIMENSIONS
5 CUSTOM DOOR PANEL INSTALLATION DIMENSIONS
6
DOOR OPENING ROTATION
7
ELECTRICAL AND PLUMBING
8
BEFORE INSTALLATION
9
ATTACH ANTI-TIP BRACKET
!0 REMOVE HINGE END CAPS
!1 CONNECT TO WATER AND ELECTRICAL SUPPLY
!2 ALIGN YOUR PRODUCT INSIDE THE CABINETRY
!3 ASSEMBLE THE DOOR PANEL SET
!4 HANG THE DOOR PANELS
!5 FIX THE BRACKETS AND RE-INSTALL THE END HINGE CAPS
!6 INSTALL WATER FILTER AND TOE KICK GRILLE
!7 ATTACH COVERS AND DOOR/DRAWER TRIMS
!8 ATTACH CABINET SIDE TRIMS
!9 FINAL CHECKLIST
CONTENTS
