Fisher & Paykel ActiveSmart RS90A Installation Guide

4
2 COMPONENTS LIST
MI (miscellaneous items) pack — included with the refrigerator
USER GUIDE
NZ AU GB IE HK SG IN US
ACTIVESMART™
INTEGRATED REFRIGERATOR
RS90A, RS9120W,
RS36A72, RS36A80 & RS36W80 models
SERVICE & WARRANTY
SERVICE ET GARANTIE
ΣΈΡΒΙΣ ΚΑΙ ΕΓΓΎΗΣΗ
SERVIZIO E GARANZIA
SERVICE & GARANTIE
HUOLTO JA TAKUU
SERVICE OG GARANTI
保修和维修
服務和保修
ACTIVESMART™ INTEGRATED
SLIDE-IN REFRIGERATOR
RS90A & RS90AU models
INSTALLATION GUIDE
NZ AU GB IE HK SG IN
844219A 07.18
User guide (1x) Service & Warranty (1x) Installation guide (1x)
Anti-tip bracket fittings — included with the refrigerator
#10x40
Pan Head
Philips Screw
#10x40
Pan Head
Philips Screw
Anti-tip bracket (1x) #10x40 pan head
Phillips screw (4x)
Masonry plug (4x)
Water filter install kit — included with the refrigerator
Water filter (1x) Collet locking clip (1x) Filter cartridge tool (1x)
External display module
(1x) (included with Water
dispensing models)
Water tap adaptor 1/4”
ODx1/2” BSP thread
(1x)
1/4” (6mm) tube (1x)
Product accessories — included with the refrigerator
Toe kick filter (1x) Toe kick grille (1x) Power cord clip (1x)
Cabinet side trim
bracket (6x)
Side cover (4x) Top cover (2x)
Door side trim (2x) Drawer top trim (1x) Drawer side trim (2x)
#8 x 5/8
Pan Head
Philips Screw
#8 x 5/8
Pan Head
Philips Screw
3M Dual Lock™ tabs
(10x)
#8x16 panhead
Philips screw (34x)
Cabinet side trim (2x)
Wood screw (2x)
