Fisher & Paykel DD60SCX7 Installation Instructions

19
ADJUST PANEL HEIGHT TO ALIGN THE CABINETRY GAPS
With the front panel fitted, insert an appropriately
sized Philips screwdriver into the hole above the
door pin and rotate the panel up or down to align
the gaps in your cabinetry.
Repeat on the other side if necessary.
The panel has a maximum travel of 2 mm up or
down.
Important!
Ensure that you maintain a minimum of 2 mm ventilation
gap below the panel.
+ or - 2 mm
20a
INTEGRATED MODELS WITH REMOTE ONLY - INSTALLING THE FRONT PANEL
