QUICK START
Use your F75 right out of the box
1. Assemble the detector (see instructions beginning page 4).
2 Install four AA alkaline batteries. All positive (button-end) terminals point up.
Batteries are included with the detector.
3. Turn the knob, located under the armrest, fully clockwise.
This turns the machine on and sets audio volume to maximum.
4. When first turned on, the F75 starts out in the Discrimination mode, with:
Sensitivity preset to 60
Discrimination Level preset to 10
Number of Tones preset to 3
Process# preset to dE
Sweep the searchcoil from side to side, parallel to the ground. Keep the searchcoil
moving over the ground. If you stop moving the searchcoil, the sound will also
stop. Probable target type will be indicated at the top of the LCD screen.
5. If the searchcoil is not in motion and not close to metal, the detector should be
silent.
6. If you experience false signals from electrical interference, from the soil itself, or
from lots of trash metal, press the MENU button.
Sensitivity will be highlighted.
Rotate the Settings knob to the left (counterclockwise),
Reduce the sensitivity setting until the false signals go away.
After 7 seconds, the machine will exit the menu and return to
normal operation.
7. Toss a coin on the ground and sweep back and forth over it a few times to get a
feel for how the machine responds.
8. You are now ready to search.
9. Pull the trigger switch with your index finger to pinpoint the exact location of
targets, making them easier to unearth.
When the trigger is pulled, PinPoint is engaged ….
The searchcoil need not be in motion to detect an object.
The 2-digit numeric display indicates approximate target depth, in inches.
