Type 304 & 304L
24
Key Description Part Number
- - - Travel Indicator, stainless steel (not shown)
1 in. (25.4mm) stem
470/80, 80 w/covered yoke, 86, 100;
657/80, 80MO, 87; 667/80, 80MO, 87 10A8487X012
1-1/4 in. (31.8 mm) stem
470/80, 80 w/covered yoke, 100, 130;
657/80, 80MO; 667/80, 80MO 10A8487X012
- - - Machine Screw, pl steel (2 req’d) (figure 13)
1 in. (25.4 mm) stem
470/80, 80 w/covered yoke, 86, 100;
657/80, 80MO, 87; 667/80, 80MO, 87 1H736528982
1-1/4 in. (31.8 mm) stem
470/80, 80 w/covered yoke, 100, 130;
657/80, 80MO; 667/80, 80MO 1H736528982
- - - Stem Bracket, pl steel
(The Type 585 and 585R size 25, 50, and 100
stem brackets were redesigned in 1988.
Actuators with old-style stem brackets must
be retrofitted with new stem brackets.)
585/25, 50 & 585R/25, 50 20B3531X012
585/100 & 585R/100 31B5649X012
Rotary Actuators
- - - Travel Indicator, stainless steel (not shown)
329; 1069/100 18A8382X012
1051/30, 40; 1052/30, 40; 1061/30 28A8489X012
1052/20 29A2423X012
1051/33; 1052/33 28A4482X012
1051/60; 1052/60, 70; 1061/40, 60, 68 28A8496X012
1061/80, 100 28A8499X012
Styles F and G mounting
1066/20, 27; 1066SR/20, 27 28A4482X012
1066/75; 1066SR/75 28A4483X012
Style H mounting
1066/20, 27; 1066SR/20, 27--7/8 in
(22.2 mm) shaft 28A4482X012
1066/27 1066SR/27--1-1/8 in
(28.6 mm) shaft 28A4483X012
1066/75 1066SR/75--1-1/8 in
(28.6 mm) shaft 28A4483X012
1066/75 1066SR/75--1-1/2 in
(38.1 mm) shaft 28A4483X012
- - - Cap Screw, pl steel (4 req’d) (not shown)
1051/30, 40; 1052/30, 40; 1061/30 1C403824052
1051/60; 1052/60, 70; 1061/40, 60, 68 1A453324052
1061/80, 100 (2 req’d) 1A440224052
- - - Self-Tapping Screw, pl steel (2 req’d) (not shown)
329; 1069/100 1B5613X0012
1051/30, 40; 1052/30, 40; 1061/30 1B561528982
1052/20 1P474328982
1051/60; 1052/60, 70; 1061/40, 60, 68 1B5613X0012
1061/80, 100 1B5613X0012
Key Description Part Number
- - - Travel Indicator Scale, stainless steel (not shown)
1051/33; 1052/33 20B1542X012
1076/3 14A7857X012
- - - Machine Screw, pl steel (2 req’d) (not shown)
1076/3 1B561528982
1078/AAA 17B0404X012
Styles F and G mounting
1066/20, 27; 1066SR/20, 27 1V730928982
1066/75; 1066SR/75 1H1581X0012
Style H mounting
1066/20, 27; 1066SR/20, 27--7/8 in
(22.2 mm) shaft 1B877628992
1066/27 1066SR/27--1-1/8 in
(28.6 mm) shaft 1B877628992
1066/75 1066SR/75--1-1/8 in
(28.6 mm) shaft 1B2752X0022
1066/75 1066SR/75--1-1/2 in
(38.1 mm) shaft 1B2752X0022
- - - Adaptor, steel (not shown)
Style H Mounting
1066/20, 27; 1066SR/20, 27--7/8 in
(22.2 mm) shaft 28A4515X012
1066/27 1066SR/27--1-1/8 in
(28.6 mm) shaft 28A4516X012
1066/75 1066SR/75--1-1/8 in
(28.6 mm) shaft 28A4517X012
1066/75 1066SR/75--1-1/2 in
(38.1 mm) shaft 28A4518X012
- - - Set Screw, stainless steel (not shown)
Style H Mounting
1066/20, 27, 75; 1066SR/20, 27, 75 12A9113X012
- - - Connector, 416 stainless steel (not shown)
1076
Size 1
3/8 in. (9.7 mm) shaft 34A1590X012
1/2 in. (12.7 mm) shaft 34A1591X012
5/8 in. (15.9 mm) shaft 34A1592X012
3/4 in. (19.1 mm) shaft 34A1593X012
7/8 and 1 in. (22.4 and 24.5 mm) Shafts 34A1594X012
Size 2
7/8 and 1 in. (22.4 and 24.5 mm) Shafts 34A4460X012
1-1/4 in. (31.8 mm) shaft 32A9785X012
1-1/2 in. (38.1 mm) shaft 32A9786X012
1-3/4 and 2 in. (44.5 and 50.8 mm) Shafts 35A1435X012
Size 3
1-3/4 and 2 in. (44.5 and 50.8 mm) Shafts 34A2039X012
2-1/2 in. (63.5 mm) shaft 31A6554X012
- - - Cover, iron (not shown)
1076/3 24A2037X012
- - - Pointer, stainless steel (not shown)
1076/3 14A2038X012
1078/A, AA 21B6945X012
1076/AAA 21B4713X012
For information, contact Fisher Controls:
Marshalltown, Iowa 50158 USA
Cernay 68700 France
Sao Paulo 05424 Brazil
Singapore 0512
Printed in U.S.A.
