12
29
Because most gold nuggets are tiny, and are usually found in soil which is
high in iron oxide minerals, serious gold prospecting requires a detector with
high sensitivity and true ground balanced All Metal operation. Run the
machine with the sensitivity high enough to hear some noise from ground
minerals, and
learn the language of the sounds you hear. Headphones are
recommended unless consideration for safety (for instance rattlesnakes) rules
them out. Move the searchcoil slowly and deliberately, carefully controlling its
height above the ground to minimize noise from iron minerals in the soil. If you
hear ground noise, your GND BAL setting could be a bit off, so perform the
ground balancing procedure again. As you walk even a very short distance,
ground conditions can change. The ground geology typically associated with
gold will tend to change over very short distances.
The Fe
3
O
4
bar graph indicates the amount of iron mineralization in the soil. In
most gold fields, especially alluvial (placer) deposits, gold tends to be
associated with iron minerals, especially magnetite
black sand. If you know
this to be the case in the area you're working, you can maximize your gold
recovery by concentrating your effort on areas where the bar graph indicates
higher amounts of iron mineralization.
Gold prospectors are mostly a friendly bunch, and willing to spend some time
showing a beginner how to increase his odds of finding the yellow stuff. Many
will invite you to search on their claims (if they have any) once they get to know
you. In some gold areas, a lot of the terrain is under claim, so you need to
learn how to recognize posted claims and stay off of them unless you have the
claim owner's permission. Prospecting clubs such as the Gold Prospector
Association of America (GPAA) often own claims which are open to its
members and sponsor group outings to productive gold prospecting areas.
It’s a thrilling experience to dig into the ground and pull out a precious piece of
yellow metal that you are the first person on earth to see. If you love being
outdoors, have patience, and can stay motivated by the prospect of finding
that next nugget, then
beeping for gold may be the hobby for you. While only
a few get rich prospecting, if you are not among them, think of it as outdoor
recreation where your finds defray the expense of having fun!
GOLD PROSPECTING
OPERATION & CONTROLS
VOLUME
V-BREAK
NOTCH WIDTH
DISCGND BAL
ON/OFF/GAIN:
• Click ON/OFF
• In DISC Mode rotate
to change GAIN
(sensitivity) from
1 to 100
• In ALL METAL Mode
rotate to change
GAIN from 5 to 100
in steps of 5
• In DISC Mode press
to cycle through
menu options
• In ALL METAL Mode
press-and-hold
while bobbing coil
to set ground balance
Press-and-hold to
activate PINPOINT feature
In DISC Mode:
Change setting of active menu option
In ALL METAL Mode:
Change Ground Balance setting from 0 to 99.9
MODE SELECTION
and THRESHOLD CONTROL
Click left to operate
in Discrimination
Mode
Click to right to
operate in ALL METAL
Mode.
Rotate knob in
ALL METAL Mode to
change THRESHOLD from
-40 to 40
POWERING UP
• Click the left knob to turn the detector ON.
After clicking the knob on, continued clockwise rotation will increase the
“sensitivity” in DISC Mode or the “GAIN” in ALL METAL Mode.
• We suggest keeping the GAIN below 70 until you become familiar with
the detector’s operation.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Fisher F19 and is the answer not in the manual?

Fisher F19 Specifications

General IconGeneral
Operating Frequency19 kHz
Battery Life20-25 hours
Water ResistanceSearchcoil is waterproof
Searchcoil10" elliptical concentric
Batteries1 x 9V
DiscriminationAdjustable
DisplayLCD
Target ID Range0-99
SensitivityAdjustable
Search ModesAll Metal, Discrimination
Ground BalanceAutomatic and Manual
Target IDYes
Audio Outputheadphone jack
Audio Tones4 tones
