Instruction Manual Supplement
D103783X012
DVC2000 Digital Valve Controller
September 2017
16
Command 48: Read Additional Status
Byte Format Description
Request
Data
bytes
0 None
Response
Data
Bytes
0 Uint8 Command 48 Response Byte 0
1 Uint8 Command 48 Response Byte 1
2 Uint8 Command 48 Response Byte 2
3 Uint8 Command 48 Response Byte 3
4 Uint8 Command 48 Response Byte 4
5 Uint8 Command 48 Response Byte 5
6 Uint8 Reserved
7 Uint8 Reserved
