Instruction Manual Supplement
D103783X012
DVC2000 Digital Valve Controller
September 2017
27
ADDITIONAL_STATUS_4 According to Command 48: As defined in the Gateway:
Bit 7 Travel Alert Lo TRAVEL_ALERT_LO
Bit 6 Travel Alert Lo Lo TRAVEL_ALERT_LO_LO
Bit 5 Travel Alert Hi TRAVEL_ALERT_HI
Bit 4 Travel Alert Hi Hi TRAVEL_ALERT_HI_HI
Bit 3 Travel Deviation Alert TRAVEL_DEVIATION_ALERT
Bit 2 Travel Limit/Cutoff Hi Alert
TRAVEL_LIMIT_HI_OR_
TRAVEL_CUTOFF_HI_IN_EFFECT
Bit 1 Travel Limit/Cutoff Lo Alert
TRAVEL_LIMIT_LOW_OR_
TRAVEL_CUTOFF_LOW_IN_EFFECT
Bit 0 Drive Signal Alert DRIVE_SIGNAL_ALERT
ADDITIONAL_STATUS_5 According to Command 48: As defined in the Gateway:
Bit 7 Reserved
Bit 6 Reserved
Bit 5 Reserved
Bit 4 Reserved
Bit 3 Reserved
Bit 2 Option Module Error LIMIT_SWITCH_ERROR
Bit 1 Limit Switch 2 Status LIMIT_SWITCH_2_CLOSED
Bit 0 Limit Switch 1 Status LIMIT_SWITCH_1_CLOSED
ADDITIONAL_STATUS_6 According to Command 48: As defined in the Gateway:
Bit 7 Reserved
Bit 6 Reserved
Bit 5 Reserved
Bit 4 Reserved
Bit 3 Reserved
Bit 2 Reserved
Bit 1 Reserved
Bit 0 Reserved
