Fisher FIELDVUE DVC2000 Instruction Manual Supplement

Instruction Manual Supplement
D103783X012
DVC2000 Digital Valve Controller
September 2017
26
ADDITIONAL_STATUS_1 According to Command 48: As defined in the Gateway:
Bit 7 Alert Record Not Empty Alert ALERT_RECORD_HAS_ENTRIES
Bit 6 Auto Tune in Progress AUTO_TUNER_IN_PROGRESS
Bit 5 Calibration in Progress Alert CALIBRATION_IN_PROGRESS
Bit 4 Diagnostics in Progress Alert DIAGNOSTIC_IN_PROGRESS
Bit 3 Pressure Fallback Active Alert PRESSURE_CONTROL_IS_ACTIVE
Bit 2 Reserved
Bit 1 Reserved
Bit 0 Auto Cal in Progress Alert AUTO_TRAVEL_CALIBRATION_IN_PROGRESS
ADDITIONAL_STATUS_2 According to Command 48: As defined in the Gateway:
Bit 7 Reserved
Bit 6 Reserved
Bit 5 Cycle Counter Alert CYCLE_COUNT_ALERT
Bit 4 Travel Accumulator High Alert TRAVEL_ACCUMULATOR_ALERT
Bit 3 Instrument Time is Invalid Alert INSTRUMENT_TIME_IS_INVALID
Bit 2 Alert Record Full Alert ALERT_RECORD_IS_FULL
Bit 1 Offline / Failed Alert OFFLINE_FAILED_ALERT
Bit 0 Reserved
ADDITIONAL_STATUS_3 According to Command 48: As defined in the Gateway:
Bit 7 Reserved
Bit 6 Reserved
Bit 5 Reserved
Bit 4 Reserved
Bit 3 Reserved
Bit 2 Reserved
Bit 1 Integrator Saturated High Alert INTEGRATOR_SATURATED_HIGH
Bit 0 Integrator Saturated Low Alert INTEGRATOR_SATURATED_LOW

Fisher FIELDVUE DVC2000 Specifications

General

Manufacturer	Fisher
Category	Controller
Device Type	Digital Valve Controller
Communication Protocol	HART
Input Signal	4-20 mA
Enclosure Rating	NEMA 4X, IP66
Operating Temperature	-40 to 85°C (-40 to 185°F)
Material	Aluminum
Power Supply	Loop Powered
Diagnostics	Advanced diagnostics
Output Signal	4-20 mA
Certifications	ATEX, IECEx, CSA, FM
Mounting	Integral mounting to actuator
