DC50 Digital Dispenser Operating Manual
© 2020 Fisnar - 6 - DC50 Rev 02
ACCESSORIES
Item
Description Quantity
5601911
Power Adaptor (Input: 100 – 240 VAC / Output: 24 VDC) 1
5601888
Foot Pedal 1
561851
Air Inlet Hose Assembly 1
560751LF
Syringe Holder 1
5779K712
Push To Connect Tube Fitting 1/4" Stem OD X 5/32" Tube OD 1
Note: Consumable kit (part # QK-CSK) & needle sample kit (part # QK-NSK) available to purchase separately.
Part # QK-CSK Part # QK-NSK
SPECIFICATIONS
Dimensions (W x D x H): 7.56” x 7.17” x 3.00” (192 x 182 x 76 mm)
Weight: 2.14 lbs (0.97 kg)
Input AC to Power
100 – 240 VAC, 50 / 60 Hz
Output DC from Power
Supply:
24 VDC – 1 Amp
Cycle Rate: Up to 600 cycles / min
Relative Humidity: 20 – 90% (No Condensation)
Operating Temperature: 50 – 104
10 – 40
Timer: 0.008 – 99.99 seconds
Air Input: 100 psi (7 bar) max
Air Output: 1 – 100 psi (0.07 – 7 bar)
Standards: CE Approved, RoHS Compliant, EMC Compliant
