LIQUID-COUPLED HEAT EXCHANGER ECONET
®
Installation & Maintenance Manual
22
FläktGroup DC_9010GB 20180327_R0 Specifications are subject to alteration without notice
NOTE: If there are more than 10 menus within one level,
the numbering continues in alphabetic order.
PROGRAMMING DURING OPERATION
Most of the parameters can be changed during operation with-
out stopping the VSD. Parameters that can not be changed are
marked with a lock symbol in the display.
NOTE: If you try to change a function during operation that only can be
changed when the motor is stopped, the message “Stop First” is dis-
played.
EDITING VALUES IN A MENU
Most values in the second row in a menu can be changed in
two different ways. Enumerated values like the baud rate can
only be changed with alternative 1.
2621 Baudrate
Stp 38400
222 Motor Freq 50Hz Frequency from motor nameplate
223 Motor Power [Motor] W Power from motor nameplate
224 Motor Curr [Motor] A Current from motor nameplate
225 Motor Speed [Motor] rpm Speed from motor nameplate
226 Motor Poles [Motor] Number of poles from motor nameplate
227 Motor Cosφ [Motor] Power factor from motor nameplate
300 Process Process and application parameters.
Hidden if not logged in.
400 Monitor/Prot Load Monitor and Process Protection
Hidden if not logged in.
500 I/Os I/Os and virtual connections
Hidden if not logged in.
600 Logic&Timers Logical functions and timers.
Hidden if not logged in.
700 Oper/Status View Motor Operation and Status
800 View TripLog View and reser logged trip data.
810 TripMessage hh:mm:ss Latest trip
820 TripMessage hh:mm:ss
830 TripMessage hh:mm:ss
840 TripMessage hh:mm:ss
850 TripMessage hh:mm:ss
860 TripMessage hh:mm:ss
870 TripMessage hh:mm:ss
880 TripMessage hh:mm:ss
890 TripMessage hh:mm:ss
8A0 Reset Trip L No Reset Trip Log
900 System Data VSD system data
Hidden if not logged in.
