LIQUID-COUPLED HEAT EXCHANGER ECONET
®
Installation & Maintenance Manual
30
FläktGroup DC_9010GB 20180327_R0 Specifications are subject to alteration without notice
SPARE PARTS LIST
List of items that can be provided as spare parts.
Ordering code: STAZ-74-bbb-c-d-e-f-g-h-i-j-k
bbb = eQ-size
POS PART MAKER TYPE NOTE
1 Bypass-valve Johnsson controls 005, 008, 009 =>BG 005 => V6 1801 – 19 – BA – 2,5
011, 014 =>BL 008, 009 => – 20 – BD – 4,0
018, 020 =>BN 011 – 014 => – 20 – BE – 6,3
023–036 =>CP 018, 070 => – 25 – BE – 10
041=>DR 023 – 036 => – 32 – BE – 16
054–090 =>ES 041, 045 => – 40 – BE – 25
108–180 =>FT 050 – 090 => – 50 – BE – 40
108 – 180 => – 50 – BF – 63
2 Single pump P40 Grundfos bbb=005 => CR1s-10 Shaft seal: HQQE
bbb=008,009 => CR1-8 Motor:380-415V Y
bbb=011,014 => CR3-8
bbb=018=> CR3-9
bbb=020 => CR3-10
bbb=023,027 => CR5-8
bbb=032,036 => CR5-9
bbb=041,045 => CR5-11
bbb=050,054,056 => CR10-5
bbb=063,068 => CR10-6
bbb=072 => CR10-7
bbb=079,090,108 => CR15-4
bbb=126,135,144 => CR20-4
bbb=158 => CR20-5
bbb=180 => CR32-3
3 One frequency inverter Emotron bbb=005,008,009
bbb=011,014,018,020 => FDU 48 – 003 – 54 – C – F
bbb=023,027,032,036 => FDU 48 – 004 – 54 – C – F
bbb=041,045,050,054,056,063,068 => FDU 48 – 006 – 54 – C – F
bbb=072 => FDU 48 – 008 – 54 – C – F
bbb=079, 090,108 => FDU 48 – 010 – 54 – C – F
bbb=126,135,144,158,180 => FDU 48 – 013 – 54 – C – F
4 Temperature sensor, GT40 Thermocon or similar TF 14 4x100 PT 1000
5 Temperature sensor, GT41 Thermocon or similar TF 14 4x100 PT 1000
6 Temperature sensor, GT42 Thermocon or similar TF 14 4x100 PT 1000
7 Pressure switch, PS40 Distributor Ahlsell Pressure switch
8 Pressure sensor, GP41 Huba Control Huba part.nr.
DistributorWexon 692.918001141
Wexon DTP 4-010
9 Valve actuator Johnsson controls 24VDC M9108 – GGA – 5
