LIQUID-COUPLED HEAT EXCHANGER ECONET
®
Installation & Maintenance Manual
26
FläktGroup DC_9010GB 20180327_R0 Specifications are subject to alteration without notice
Register address Descritption Values/Unit Remark
3x0060 Scale liquid pressure sensor xxx kPa (fac1)
3x0061 Liquid pressure lower xx.y kPa (fac10)
3x0062 Liquid flow lower xx.yy l/s (fac100)
3x0063 Liquid pressure upper xx.y kPa (fac10)
3x0064 Liquid flow upper xx.yy l/s (fac100)
3x0065 Scale air pressure sensor xxx Pa (fac1)
3x0066 K-factor supply air xx.yy (fac100)
3x0068 Laminar nominal flow xx.yy l/s (fac100)
3x0070 Optimal heating air flow lower xx.y m3/s (fac10)
3x0071 Optimal heat in a liquid flow lower xx.yy l/s (fac100)
3x0072 Optimal heating air flow upper xx.y m3/s (fac10)
3x0073 Optimal heating liquid flow upper xx.yy l/s (fac100)
3x0074 Optimal cooling recovery air flow lower xx.y m3/s (fac10)
3x0075 Optimal cooling recovery liquid flow lower xx.yy l/s (fac100)
3x0076 Optimal cooling recovery air flow upper xx.y m3/s (fac10)
3x0077 Optimal cooling recovery liquid flow upper xx.yy l/s (fac100)
3x0078 Optimal cooling air flow lower xx.y m3/s (fac10)
3x0079 Optimal cooling liquid flow lower xx.yy l/s (fac100)
3x0080 Optimal cooling air flow upper xx.y m3/s (fac10)
3x0081 Optimal cooling liquid flow upper xx.yy l/s (fac100)
3x0082 Idle flow setpoint xx.yy l/s (fac100)
3x0083 Idle temperature setpoint xx.y oC (fac10)
3x0084 Startup flow setpoint xx.y l/s (fac10)
3x0085 Startup time xx min (fac1)
3x0086 Frost protection setpoint xx.y oC (fac10)
3x0087 Frost protection alarm setpoint xx.y oC (fac10)
3x0088 Frost protection controller P Not used
3x0089 Frost protection controller I Not used
3x0090 Ice protection setpoint xx.y oC (fac10)
3x0091 Ice protection alarm setpoint xx.y oC (fac10)
3x0092 Ice protection controller P Not used
3x0093 Ice protection controller I Not used
3x0099 Application version number xxx (fac10) Not used
4x0001 Econet start 0= Off, 1 =On 0-1
4x0002 Cooling start 0= Off, 1 =On 0-1
4x0003 Cooling recovery start 0= Off, 1 =On 0-1
4x0004 Heating recovery input signal 0-100% (fac1)
4x0005 Supply air flow (from external system) xx.y l/s (fac10)
MODBUS ADDRESSES
