2.2 Air compressor connect to plasma cutter
2.3 Plasma Cutter Torch connect to machine
2.4 Cutting Torch
explosive chart
1.Spacer spring, 2.Outside nozzle, 3.Extend tip, 4.Electrode. These are wear parts, among which the extend tip
and electrode are very easy to wear, please keep it.
