Flavel Calibre FBFC**MN2 - Page 17

3.1.3 Place the front left coal moulding onto the front coal support as shown
below in figure 14.
Fig. 14
3.1.4 Place the upper right coal moulding as shown below in figure 15. This
moulding tucks under the front right coal moulding and is supported by
the ceramic fibre support.
Fig. 15
17
Left Front Coal Moulding
Upper Right Coal Moulding
