Flavel Calibre FBFC**MN2 - Removal; Replacing the Fuel-Bed

5.10 REMOVING / REPLACING THE FUELBED
5.10.1 Remove the trim, fret & ashpan or fascia. Remove the glass frame
assembly as shown in section 5.9. Place the ceramic fibre support
behind the burner as shown below in figure 15.
Fig. 15
5.10.2 Place the front right coal moulding onto the front coal support as shown
below in figure 16.
Fig. 16
Right Front Coal Moulding
Front Coal Support
59
