Flavel Calibre FBFC**MN2 - Page 60

5.10.3 Place the front left coal moulding onto the front coal support as shown
below in figure 17.
Fig. 17
5.10.4 Place the upper right coal moulding as shown below in figure 18. This
moulding tucks under the front right coal moulding and is supported by
the ceramic fibre support.
Fig. 18
L
eft Front Coal Moulding
60
Upper Right Coal Moulding
