PAGE 15Help: 888-426-5001 QualityWaterForLess.com
fIGure 15-a fIGure 15-b
fIGure 15-c
fIGure 15-d
8 ›ProGraMMInG tHe flecK 9000 sXt ValVe
1) To begin programming, first plug in your 9000
Valve to a nearby wall outlet. The system will
illuminate 4 digits. The system will show the
time of day and the amount of gallons remaining
before the next regneration. This display will
switch between these values about every 10
seconds
2) Set the time on the system to 12:01 PM by
pressing either the UP or DOWN button as
shown in Figure 15-A.
i
Be careful to confirm
the presence of the PM symbol in the top
right corner.
You may hold the button to allow
the time to scroll faster. Once the time display is
set to 12:01 PM, press the REGEN button once
as shown in Figure 15-B
3) To enter MASTER PROGRAMMING MODE,
press the UP and DOWN buttons TOGETHER
and HOLD both for 5 seconds as shown in
Figure 15-C
4) The display should now show
DF / GAL
as shown
in Figure 15-D. This indicates U.S. Operational
Mode measuring consumption in gallons. Do not
change this value and press the REGEN button
once to advance to the next setting
fIGure 15-e
fIGure 15-f
5) The display should now show
VT / dF1b
as
shown in Figure 15-E. This indicates Regeneration
Flow Downflow Single Backwash. Do not change
this value and press the REGEN button to advance
to the next setting
6) The display should now show
CT / FI
as shown in
Figure 15-F. This indicates Control Type Meter Im-
mediate Mode. Do not change this value and press
the REGEN button to advance to the next setting
To Next Page
