ELEcTRicAL
SYSTEMS
3.
If
the RESET button does not pop out when the test button
is
pushed, a loss of ground fault protection is indicated. Do
not use any
electrical outlets. Have the motor home electri-
cal
system checked at an authorized Fleetwood Service
Center or by a
qualified electrician. Do not use the system
until the
problem has been corrected.
4.
To
restore power push the RESET button.
Your Owner's Information Package contains a card that can
be used to record test dates. Keep the card in a conspicuous
place and keep it up to date.
Because
of
the many model, floor plan and option variations
available, detailed wiring diagrams are not included in this
manual. In certain situations, specific wiring diagrams may
be available to help troubleshoot a problem.
If
you need spe-
cific wiring information, please contact your Fleetwood man-
ufacturing facility.
WARNING
Do
not install 12-volt
fuses or 120-volt break-
ers with amperage
rat-
ings greater than that
specified
on
the device or
label. Doing so consti-
tutes a fire hazard.
ELECTRICAL
DIAGRAMS
BOUNdER
DiESEl
