i:!:..
~
"
1.
AlC
Outlet
2.
Instrument
Cluster
- (Consult Chassis Operator's/Owner's
Guide/Manual)
3. Utility
Light
Switch
4. Drivers
2·Speed
Fan
Switch
5. Luggage
Compartment
Light
Switch
6.
Generator Hour Meter
7.
Passenger's
2~Speed
Fan Switch
8. Radio/Cassette
Player
9. Cigarette
Lighter
10.
Cab
Heater/AIC Controls - (Driver/cockpit area only)
Temperature
Control
Lever
- Adjusts the temperature
of
the air
coming out
of
the outlets. Move the lever to the left for cooler,
and the right for wanner.
Fan
Speed Switch - Turns the fan ON and OFF. and adjusts the
fan speed.
Air
Intake
Button
(RECIRC) - Selects the source
of
the air
being warmed
or
cooled. When the button is pressed (RECIRC),
interior air is recirculated through the system. When the button is
out, air from outside the vehicle is
drawn through the system.
Normally. set the button out to circulate fresh
air from outside.
The RECIRC mode may be used when you desire faster cooling
or
heating.
or
if
outside air is unusually dusty
or
odorous.
Air
Flow
Control
Buttons
- Directs the air to the desired
outlets.
VENT
~
When this button is pushed, either wanued
or
cooled air
comes out
of
the adjustable dash mounted outlets.
BIL
~
Bi-Ievel. Air comes out
of
both the dash and floor outlets.
FLOOR
-
Air
comes out
of
the floor outlets, with some air
directed to the windshield to prevent fogging.
DEF
- Air comes out
of
the windshield outlets to defrost the
windshield.
Set the fan switch to HI and the temperature lever to
the far right for maximum defrosting.
Air
Conditioning (AlC) On-OtT
Button
- Turns air
conditioning compressor on and off. When
air conditioning is
desired. press this button in and set the fan switch to any position
except
OFF.
AlC
Indicator
Light
- This will light when the AlC button
is on.
In
the defrost (DEF) mode. the compressor will
come on whether
or
not the
NC
ON-OFF button is on.
This helps to reduce the moisture in the
air going to
the defroster outlets.
11.
Generator
Start
Switch
12.
Ignition
Switch
13.
Parking
Brake
Control
14.
Headlight
Switch
15. Windshield
WiperlWasher
2-Speed Windshield WiperlWasher
OFF - No wiper action.
1st notch - Wiper delay
ON. Turn outer knob clockwise for
longer delay between wiper strokes.
2nd notch -
Slow wiping action. 3rd notch - Fast wiping action.
To
WASH - Press inner knob, then release. One press
of
the
washer
mob
cycles wipers once. The washer nozzles are located
on the wiper anus close to the wiper blades and move with the
blades to provide continuous washer coverage.
16. Auxiliary
Start
Switch
The Auxiliary Start System allows you to use the coach battery to
start the motor home engine
if
the chassis battery is discharged.
To
use the system. push and hold the button and
tum
the ignition
key to start the engine. Release the button and key switch when
the engine starts.
If
both the chassis and coach batteries are dead. the engine will
not crank. Sufficient cranking charge may be restored to the
coach batteries by plugging in to an external 120volt
AC
electri-
cal source or by running the generator.
The Auxiliary
Start System has no effect on the vehicle except to
aid in starting the motor home engine.
If
the vehicle alternator is
operating properly, the batteries
will
be recharged while driving
(see
"Electrical System" chapter).
Note:
If
extended normal driving does not recharge the batteries,
see
an
authorized Fleet'Nood motor home service center.
17.
Fog
Lamp
Switch
12V
Power
Connector
Systems
Monitor
Panel
"
==
....
~
lit'
~
Q
4!
i!
Q
~
