The 120-volt circuit breakers and l2-volt fuses are located
on three separate panels. The purpose
of
these three panels is
to provide electrical circuit breakers and fuses to interrupt
current flow
if
a circuit is overloaded.
1.
120-volt House
Electrical-
This electrical panel
is
locat-
ed
in an overhead cabinet
in
the galley. This panel is very
similar to a residential panel with resettable breakers.
2.
Fleetwood Automotive 12-volt System - This panel
is
located on the right side under the hood. This electrical
center contains battery disconnect systems, entry step
and some other automotive circuitry.
3. 12-volt Chassis Fuses - This electrical
panelis
located
under the driver's side instrument panel.
PACE
Annow
ELECTRicAL
SYSTEMS
MOTOR
HOME
FUSES
AND
CIRCUIT
BREAKERS
WARNING
Do
not install 12-volt
fuses
or
120-volt break-
ers with amperage rat-
ings greater than that
specified
on
the device or
label. Doing so consti-
tutes a fire hazard.
06-11
1=.-.
I--~
