ELECTRicAL
SYSTEMS
The dual air conditioners are controlled by the Electronic
Climate Control system. This system allows both automatic
and manual control
of
the rooftop air conditioners and the
furnace(s) in your motor home.
The system will automatically control the air conditioner
temperature, and when in the
AUTOMATIC mode, it will
control the fan speed
to
provide the necessary cooling at the
quietest fan speed.
The system also monitors the current being drawn by all the
electrical appliances in the motor home.
Since the air condi-
tioners draw a large amount
of
current, the climate control
system may turn them off
to
prevent circuit overload. Once
the system turns them off, it will keep them off as long as
required, and then automatically return them to normal
operation.
The system is designed to operate from 120-volt, 30-amp AC
service
ONLY.
Connection
of
the motor home to any other
power source will cause
improper operation
of
the system.
If
only 20-amp service is available, current load management
must be done manually by the owner and only one air condi-
tioner can be operated at
anyone
time.
ELECTRONIC
CLIMATE
CONTROL
SYSTEM
"'I
NOTE
A troubleshooting guide
and function manual that
explains this system
is included with your
motor home
Owner's
Information Package.
Because
of
the many model, floor plans and option variations ELECTRICAL
available, it is beyond the scope
of
this manual
to
include
wiring diagrams. In certain situations, specific wiring dia-
WI
RI NG
DIAGRAMS
grams may be available to help troubleshoot a problem.
If
you need specific wiring information, please contact your
dealer. Complete wiring diagrams are not available.
