Flex XFE 15 18.0-EC User Manual

Instruction manual XFE 15 18.0-EC / XCE 8 18.0-EC
10
Operating instructions
WARNING
Risk of electric shock! Before carrying out
any work on the power tool, always remove
the battery.
Before switching on the power
tool
Unpack the polisher and check that there
are no missing or damaged parts.
NOTE
The batteries are not fully charged on
delivery. Prior to initial operation, charge
the batteries fully. Refer to the charger
operating manual.
Inserting/replacing the battery
– Press the charged battery into the power
tool until it clicks into place.
– To remove, press the release button (1.)
and pull out the battery (2.).
CAUTION
When the device is not in use, protect the
battery contacts. Loose metal parts may
short-circuit the contacts; explosion and fire
hazard!
Battery state of charge
– Press the button to check the state of
charge at the state of charge indicator
LEDs.
The indicator goes out after 5 seconds.
If one of the LEDs flashes, the battery must
be recharged. If none of the LEDs light up
after the button is pressed, the battery is
faulty and must be replaced.
Attaching or changing
the polishing tool
– Remove the battery.
– Firmly press polishing tool, centred on
theeye, onto the Velcro pad.
Useundamaged polishing tools only.
– Insert the mains plug into the socket.
– Switch on the polisher (without
engaging it) and run the polisher for
approx. 30seconds. Check for
imbalances andvibrations.
– Switch off the polisher.

Flex XFE 15 18.0-EC Specifications

General

Battery Voltage	18 V
No Load Speed	3, 000 - 10, 000 opm
Weight	3.5 lbs
Dust Extraction	Yes
Max. disc diameter	6 in (150 mm)
Pad Size	6 in (150 mm)
Orbit	2.5 mm
