XFE 15 18.0-EC / XCE 8 18.0-EC Instruction manual
9
Overview
1 Grip hood
With air outlet and direction-of-rotation
arrow.
2 Gear head *
3 Dial for preselecting the speed
4 Locking button
Locks the switch (5) during continuous
operation.
5Switch
Switches the power tool on and off and
also accelerates it up to the
preselected speed.
6 Filter cover
7 Slot for battery
8 Rating plate *
9 Velcro pad
10 Disc support
11 Li-ion battery (2.5 Ah or 5.0 Ah)
12 Release button for battery
13 State of charge indicator
14 Grip area
Torx wrench T20 *
* not illustrated
