Flexim FLUXUS F704**-A2 Series User Manual

13 Libraries FLUXUS F70x
UMFLUXUS_F7V4-6-2EN, 2017-10-01 121
13 Libraries
The internal material database of the transmitter contains parameters for pipe and lining materials as well as for media. It
can be extended with user-defined materials or media. User-defined materials and media will always be displayed in the
scroll lists of the program branch Parameter.
User-defined materials and media can be stored in an integrated coefficient memory (user area). The coefficient memory
has to be partitioned first (see section 13.1).
The parameters of user-defined materials or media can be entered as follows:
• as constants without the extended library (see section 13.2)
• as constants or temperature and pressure dependent functions by means of the extended library (see section 13.3)
The material and media scroll lists displayed in the program branch Parameter can be arranged (see section 13.5).
Shorter scroll lists make working more efficient.
13.1 Partitioning of the Coefficient Memory
The coefficient memory can be divided into parts for the following material data:
• material parameters:
– transversal and longitudinal sound speed
– typical roughness
• medium parameters:
– min. and max. sound speed
– kinematic viscosity
–density
• heat flow coefficients (additional medium parameter)
• steam coefficients (additional medium parameter)
For the max. number of data sets for each category of these material data see Tab. 13.1.
Tab. 13.1: Capacity of the coefficient memory
max. number
of data sets
occupancy of the
coefficient memory in %
materials 13 97
media 13 97
heat flow coefficients 29 98
steam coefficients 19 95
Select Special Funct.\SYSTEM settings\Libraries\Format USER-AREA.
Press ENTER.
This error message will be displayed if the entered number of data sets for a category of
material data exceeds the capacity of the coefficient memory.
Enter the number of the user-defined materials. Press ENTER.
Enter the number of the user-defined media. Press ENTER.
Enter the number of user-defined data sets for the heat flow coefficients. Press ENTER.
Heat flow coefficients can only be entered if the transmitter has temperature inputs.
Enter the number of user-defined data sets for the steam coefficients. Press ENTER.
Steam coefficients can only be entered if the transmitter has temperature inputs.
Libraries ↕
Format USER-AREA
MAXIMAL: 13!
Materials: 15
Format USER-AREA
Materials: 03
Format USER-AREA
Media: 03
Format USER-AREA
Heat-Coeffs: 00
Format USER-AREA
Steam-Coeffs: 00
