FLUXUS F70x A Menu Structure
168 UMFLUXUS_F7V4-6-2EN, 2017-10-01
input of the number of sound paths
display of the transducer distance to be adjusted between the inner edges of the
transducers
Program Branch Output Options
main menu: selection of the program branch Output Options
selection of the channel whose output options are to be defined
selection of the physical quantity
selection of the unit of measurement for the physical quantity
activation of a temperature input
This display will only be indicated if the temperature input T1 has been assigned
to the channel in Special Funct.\SYSTEM settings\Proc. inputs\
Link temperature.
activation of a current input for an external temperature measurement
This display will only be indicated if the input I1 has been assigned to the chan-
nel in Special Funct.\SYSTEM settings\Proc. inputs\Link other
inp..
input of the duration over which a floating average of the measured values has
to be determined
range: 1...600 s
activation of the data logger
activation of the measured value transmission to a PC or a printer via the serial
interface
selection of the storage rate for storing measured values in the data logger
This display will only be indicated if Output Options\Store Meas.Data
and/or Serial Output are activated.
Input of the storage rate if Storage Rate = EXTRA has been selected
range: 1...43 200 s (= 12 h)
Current Loop
activation of a current output
This display will only be indicated if the current output has been installed in
Special Funct.\SYSTEM settings\Proc. outputs.
selection whether the sign of the measured values is to be considered for the
output
This display will only be indicated if Current Loop is activated.
INIT-
resistant
Transd. Distance
A:54 mm Reflex
par mea >OPT< sf
Output Options
Output Options ↕
for Channel A:
Physic. Quant. ↕
Volume flow
Storage Rate ↕
Once per 10 sec.
Meas.Values
>ABSOLUT< sign
To Next Page
