Accessory Package
Specifications Step 1
01 02
Figures shown are for reference only. Please contact customer service if there are any accessory or
tools missing.
Attaching the desk feet (1) to the legs (2&3) using 8 M6x16mm bolts (A). Tighten with 5x5 hex key (C).
Step 2
Turn the legs (2) down like ①.Attach the beam to the legs using M8x50mm bolts (B) and tighten
with 5x5 hex key (C). Then attach the desk leg (3) like ②.
Parts Included Diagram of Components
1
1
1
1
1
NO. Parts
Qty
NO. Parts
Qty
NO. Parts
Qty
2 3
4 5 6
7 8 9
10
2
1
2
1
1
4
Max. Weight Capacity
154 Ibs (70 kg)
Max. Speed
1"/s
Input Voltage
100 - 240 V
Min. Height
28" (710 mm)
Max. Height
47.6" (1210 mm)
32º - 104º F
Duty Cycle
10% (Working 2 minutes then stop 18 minutes)
Working Temperature
Desktop size
39.3" - 63" (1000 - 1600 mm) in width
and 19.7" - 31.5" (500 - 800 mm) in depth
A
x12
M6X16mm
5x5
C
x1
E
x1
2.5x2.5
B
x4
M8X50mm
D
x14
ST4.2X20mm
F
x2
M4X6mm
x1
G
Desk foot Desk leg Desk leg
Beam
Transmission
rod
Bracket
Adapter
Power
cord
Baffle
C
5x5
A
x8
C
4
2
B
Tighten
Loosen
Stretch
C
I n s t a l l b e a m ( 4 )
1
2
B
C
3
x4
B
5x5
C
Cable tie
I n s t a l l d e s k f e e t ( 1 )
To Next Page
