Aircraft Type: CTSW
FLIGHT DESIGN
Aircraft Operating Instructions
Page: 10-1
AU 010 01000
Rev. No: 7
Original Issue Date: 28-Feb-2005
Revision Date: 29-Apr-2008
10 Required Placards and Markings
10.1 Airspeed indicator range markings
Aircrafts with LSA registration
Marking Speed Range
White range (flap operating range) 72 … 115 km/h 39 ... 62 kts
Green range (normal operating range) 81 [91*]..222 km/h 44 [49*]... 120 kts
Yellow range (caution range) 222 … 269 km/h 120 ... 145 kts
Red line (never exceed speed) 269 km/h 145 kts
* - with flaps in (-12º) position
Aircrafts with LTF registration
Marking Speed Range
White range (flap operating range) 72 … 115 km/h 39 ... 62 kts
Green range (normal operating range) 94 … 245 km/h 51 ... 132 kts
Yellow range (caution range) 245 … 260 km/h 132 ... 140 kts
Red line (never exceed speed) 301 km/h 163 kts
Aircrafts with BCAR Section S registration
Marking Speed Range
White range (flap operating range) 61 … 122 km/h 33 … 66 kts
Green range (normal operating range) 74 … 219 km/h 40 … 118 kts
Yellow range (caution range) 219 … 278 km/h 118 … 150 kts
Red line (never exceed speed) 278 km/h 150 kts
10.2 Operating limitations on instrument panel
MAX: RPM 5800, EGT 1616F, CHT 248F, Oil Temp. 266F, Oil Press. 102 psi
or
MAX: RPM 5800, EGT 880ºС, CHT 120ºС, Oil Temp. 130ºС, Oil Press. 7 bar
10.3 Passenger Warning
The warning* “This aircraft was manufactured in accordance with Light Sport Aircraft
airworthiness standards and does not conform to standard category airworthiness
requirements” is placed on the instrument panel or in a place where a passenger will
see it.
* - actual for aircrafts with LSA registration only
