Appendix 2. Variants of instrument panels
Symbolic notations
1 Dynon EFIS 100 Flight information system
2 Dynon EMS 120 Engine monitoring system
3 Autopilot CT Pilot 2 Axis (Digiflight II)
4 Air Speed Indicator
5 Altimeter
6 Radio Garmin SL series & Transponder GTX series
7 Radio King KY series & Transponder KT series
8 GPS Garmin 496
9 -
10 Air speed indicator D 80mm
11 Three pointer altimeter D 80mm
12 Variometer D 57mm
13 Slip & bank indicator
14 UMA analogs (RPM meter, Oil pressure, Oil temperature,
Cylinder head water temperature, Volt meter*)
15 Hobbs hour counter
16 Trutrack ADI
* - Volt meter excluded on CTSW Classic Light ready to fly modification.
