Flight Systems Xtender - Wiring Instructions; 93-M1005

 When connecting cables to the backside of Xtender, be sure to
c
onnect with suitable position.
 When connecting cables to OUTPUT, be cautious not to
confuse
polarity (+) & (-).
 93-M1005
1
2
TEMP.SENSOR :
Connect Temp. Sensor with Model PC-100 provided
3
CIRCUIT BREAKER :
Xtender Protection Device: It will automatically cut electricity off during the excessive
current or a power failure.
4
OUTPUT :
Battery has polarity of (+) & (-). Be sure that they are connected correctly.
5
INPUT :
Electricity power / AC 3 Phases 220V 60Hz / L1, L2 ,L3 3Wires
GROUND :
Xtender to Earth Ground
1
2
3
4
5
 Wiring Instructions
