IRCamSafeEX-AXB/C Ex d enclosures for infrared cameras
8
In potentially explosive atmospheres, the device must only be operated accord-
ing to these operating instructions.
8.3.1 Permitted attachments
The following camera and lens combinations can be used.
Camera Lens AXB model
6
AXC model
A3XX
7
SC3XX
6
Without ancillary lens X X
45° ancillary lens, focal
length = 10 mm
X X
15° ancillary lens, focal
length = 30 mm
6
X X
6° ancillary lens, focal
length = 76 mm
6
X X
90° ancillary lens, focal
length = 4 mm
6
X X
A615
6
SC6XX
6
15° lens, focal length =
41.3 mm
X X
25° lens, focal length =
24.6 mm
X X
45° lens, focal length =
13.1 mm
X X
Installation work must only be carried out by specialist personnel
The attachments must be assembled by the manufacturer or by personnel au-
thorized by the manufacturer.
8.3.2 Permitted cable glands and connectors
There are two pressure-resistant, flameproof cable glands to connect the power supply
line and the data transmission line. Alternatively, pressure-resistant, flameproof connec-
tor systems can be used. The cable glands and connectors are preassembled by the
manufacturer. The enclosure can also be supplied by the manufacturer with the connec-
tion cables already connected.
The following EX cable glands can be used with the protective enclosure.
Manufacturer Reference Size Sheath diameter
A1 (mm)
Maximum num-
ber of single
wires
Stahl 8163/2-20S/16-
PXSS2K-M20
20s/16
3.1–8.7 15
Stahl 8163/2-20S-
PXSS2K-M20
20s 6.1–11.7 15
Stahl 8163/2-20-
PXSS2K-M20
20 6.5–14.0 15
Stahl 8163/2-20S/16-
PX2K-M20
20s/16
6.1–11.5 15
Stahl 8163/2-20S-
PX2K-M20
20s 9.5–15.9 15
Stahl 8163/2-20-PX2K-
M20
20 12.5–20.9 15
Hummel EXIOS Barrier
1.606.2000.50
20-1 6–12 8
#T559891; r.18204/18204; en-US
10
6. Comment from FLIR Systems: Not supported.
7. Comment from FLIR Systems: Only FLIR A310 supported.
