IRCamSafeEX-AXB/C Ex d enclosures for infrared cameras
8
8.5 Technical data
General technical data:
• Normal operating conditions temperature range T
a
: –20°C to +40°C.
• Protection class: IP67.
• Weight: 6.7 kg (without camera and lens).
• Total capacity: 5.06 L.
• External dimensions (excluding canopy and connections), diameter × length: 170 mm
× 408 mm.
• Enclosure material: aluminum.
• Surface: powder coated.
• Material for infrared transparent window: germanium; anti-reflective coating on both
sides; hard carbon coating on the exterior.
• Maximum power of auxiliary heater: 16 W.
• Operating voltage: 115 V AC 60 Hz/230 V AC 50 Hz/24 V DC.
• Maximum electrical connected load: 60 W.
• Integrated controller:
• Four-port switch with two 100Base-FX fiber-optic lucent connectors or two RJ45
(10/100) uplinks.
• Suitable for ring topology to reduce the amount of cabling required.
• Two internal temperature sensors, humidity sensor, and pressure sensor.
• Switchable camera power supply and auxiliary heating via Modbus TCP/IP.
• Web interface for configuration.
Explosion protection data:
• For use in potentially explosive atmospheres categorized as zones 1 and 2.
• Type of protection: flameproof enclosure “d.”
• Maximum surface temperature in line with temperature class T6: maximum 85°C.
• ATEX marking—AXB
9
model:
• Gas explosion protection: II 2G Ex d IIB T6 Gb.
• ATEX marking—AXC model:
• Gas explosion protection: II 2G Ex d IIC T6 Gb.
• Dust explosion protection: II 2D Ex tb IIIC T85° Db IP67.
• Inspection document: ZELM 12 ATEX 0485 X.
#T559891; r.18204/18204; en-US
12
9. Comment from FLIR Systems: Not supported.
