FLIR C3 User Manual

Technical data8
8.4 FLIR C2
P/N: 72001-0101
Rev.: 41167
Imaging and optical data
NETD 100 mK
Field of view
41° × 31°
Minimum focus distance
• Thermal: 0.15 m (0.49 ft.)
• MSX: 1.0 m (3.3 ft.)
Focal length 1.54 mm (0.061 in.)
Spatial resolution (IFOV) 11 mrad
F-number 1.1
Image frequency 9 Hz
Focus Focus free
Detector data
Focal Plane Array Uncooled microbolometer
Spectral range
7.5–14 µm
Detector pitch 17 µm
IR sensor size 80 × 60
Image presentation
Display (color)
• 3.0 in.
• 320 × 240 pixels
Display, aspect ratio 4:3
Auto orientation Yes
Touch screen Yes, capacitive
Image adjustment (alignment calibration) Yes
Image presentation modes
Infrared image Yes
Visual image Yes
MSX Yes
Gallery Yes
Measurement
Object temperature range –10°C to +150°C (14 to 302°F)
Accuracy
±2°C (±3.6°F) or 2%, whichever is greater, at 25°C
(77°F) nominal.
Measurement analysis
Spotmeter On/off
Emissivity correction Yes; matt/semi-matt/semi-glossy + custom value
Measurements correction
• Emissivity
• Reflected apparent temperature
#T559918; r. AN/42281/42281; en-US
26

FLIR C3 Specifications

General

Temperature Range	-10°C to 150°C (14°F to 302°F)
Field of View	41° x 31°
Thermal Sensitivity	<0.10°C
Accuracy	±2 °C or ±2% of reading
Resolution	80 x 60 pixels
Image Storage	Internal memory
Connectivity	Wi-Fi
Display	3-inch touchscreen
Image Modes	Thermal, MSX, Picture-in-Picture
Digital Camera	640 x 480 pixels
File Format	JPEG
Battery Life	4 hours
Dimensions	125 x 80 x 24 mm (4.9 x 3.1 x 0.94 in)
Operating Temperature	-10°C to +50°C
