Quick Start (en)
INTRODUCTION
The DM286 is a top-of-the-line digital multimeter with all the bene-
fits of a FLIR thermal imager. MSX allows you to determine if a sur-
face is hot without physically touching it. To obtain the latest version
of the comprehensive user manual, customer support, and addi-
tional product information, see the Customer Support section.
QUICK STEPS
1. Turn the rotary function switch from the OFF position to switch
the meter on.
2. If the display does not switch on, replace the TA04 battery with
a fully charged one.
3. Press the IGM button to switch the thermal imager on.
4. Target a surface and read its temperature on the upper left hand
corner of the display.
5. Explore the menu options, control buttons, and display icons, as
covered briefly in this Quick Start and in the comprehensive
User Manual.
6. Press the IGM button to switch the imager off.
7. The last section of this Quick Start provides illustrated examples
of multimeter electrical test configurations.
8. Turn the rotary switch to the OFF position to switch off the meter.
SAFETY
Before operating the device, you must read, understand, and follow
all instructions, dangers, warnings, cautions, and notes in this Quick
Start and in the User Manual, available on the support site (see
Customer Support section).
WARNING
• Do not operate the device if you do not have the correct knowledge. Incor-
rect operation can cause damage, shock, injury, or death to persons.
• Do not start a measuring procedure before you have set the function
switch to the correct position. Failure to do so can cause damage to the in-
strument and can cause injury to persons.
• Before each use, verify tester operation by measuring a known voltage.
• Do not measure the current on a circuit when the voltage increases to
more than 1000 V. This can cause damage to the instrument and can
cause injury to persons.
#NAS100145; r. AB/90267/90278; en-GB
1
