Measure mV or Temperature (thermocouple) through the
probe inputs.
Measure Resistance, Continuity, Diode, and Capacitance
through the probe inputs.
Measure Current through the probe inputs.
CONTROL BUTTONS
Several multimeter switch positions offer more than one op-
tion, press MODE to select the desired mode.
From Auto range mode, short press to select Manual range
(not available for all functions).
From Manual mode, short press to change the range. Long
press to return to Auto range.
Short press to open/close the Thermal Imager.
OK button with navigation arrows, used to confirm/change
settings and to navigate menus.
Press to exit menus.
Short press to freeze/unfreeze displayed measurements (Da-
ta Hold). Long press: Worklight ON/OFF.
Short press to capture an image. Long press to start/stop vid-
eo recording.
DISPLAY ICONS
FLEX Clamp
Data Logger
Laser pointer
Data Hold
Relative mode
Auto Range
#NAS100145; r. AB/90267/90278; en-GB
4
