Working with image modes12
Thermal
Thermal MSX
Picture in picture
Digital camera
12.3 Selecting an image mode
Follow this procedure:
1. Push the navigation pad to display the menu system.
2. Select
(Image mode) and push the navigation pad. This displays a submenu.
3. Use the navigation pad to select one of the following:
•
(Thermal MSX).
•
(Thermal).
•
(Picture in picture).
•
(Digital camera).
Note If the *.csq video format is selected (Settings > Save options & storage > Vid-
eo compression) and the recording mode Video is selected (Settings > Recording
mode), it will only be possible to select the image mode Thermal.
4. Push the navigation pad to confirm and exit the menu mode.
5. If Picture in picture mode is selected, you can at this point move and resize the infra-
red image frame. (For some camera models, the image frame is locked in the center
and cannot be moved.) Do the following:
5.1. To activate the Picture in picture tool, touch a corner of the infrared image
frame. The tool is now displayed showing five handles, one in the middle and
one in every corner of the frame.
5.2. To move the frame, touch and hold the middle handle and drag the frame.
5.3. To resize the frame, touch and hold one of the corner handles and drag the
corner of the frame.
#T810587; r. AD/90967/90989; en-US
78
