Handling the camera
7
5. In the camera, align the thermal and visual images (indicated by the two squares in
the image below), using the touchscreen arrows. The lens–camera combination is
now calibrated.
To repeat the procedure at a later time, go to Settings > Device settings > Camera infor-
mation > Calibration > Calibrate lens....
7.17 Calibrating the compass
It is recommended that the compass is calibrated every time you move the camera to a
new location.
Follow this procedure:
1. Push the navigation pad to display the menu system.
2. Select
(Settings) and push the navigation pad. This displays the Settings menu.
3. Use the navigation pad to select Device settings > Geolocation > Compass.
4. Make sure the compass is enabled by toggling the switch.
5. Select Calibrate compass and push the navigation pad. Follow the on-screen
instructions.
Note You must rotate the camera slowly.
#T810587; r. AD/90967/90989; en-US
57
