FLIR F-Series User Manual

427-0030-00-12 Rev170 Mar 2014 1-11
1 F-Series Camera Installation
1.8 F-Series Camera Specifications
Note
Power consumption is independent of the input voltage when the heater is off. The power drawn by
the heaters increases with the input voltage to a maximum at 30 Volts.
13 mm, 25 mm, 35 mm,
Resolution
THERMAL CAMERA SPECS
Detector Type Long-Life, Uncooled
VO× Microbolometer
Pixel Pitch 25 μm
Focal Length (lens/model dependent) 9 mm, 13 mm, 19 mm 9 mm, 13 mm, 19 mm,
35 mm, 65 mm, 100 mm
Field Of View (lens/model dependent) 24° × 20° (F-124; 9 mm)
17° × 14° (F-117; 13 mm)
12° × 10° (F-112; 19 mm)
48° × 39° (F-348; 9 mm)
34° × 28° (F-334; 13 mm)
24° × 19° (F-324; 19 mm)
13° × 10° (F-313; 35 mm)
7° × 5° (F-307; 65 mm)
4.6° × 3.7° (F-304; 100 mm)
45° × 37° (F-645; 13 mm)
Zoom (model dependent) 2× E-zoom 2× & 4× E-zoom
Spectral Range
Focus Range Athermalized, focus-free
50 mm, 65 mm, 100 mm
12° × 10° (F-612; 50 mm)
2× & 4× E-zoom
25 μm 17 μm
25° × 20° (F-625; 25 mm)
18° × 14° (F-618; 35 mm)
10° × 8° (F-610; 65 mm)
6.2° × 5° (F-606; 100 mm)
320 x 240160 x 120 640 x 480
Continuous e-zoom
on F-6xxE models
ENVIRONMENTAL
Dust, Water Protection Rating IP66
Operating Temperature
Cold start
-50°C to +70°C (-58°F to +158°F);
-40°C to +70°C (-40°F to +158°F)
OUTPUTS
Composite Video NTSC or PAL Standard
Video Over Ethernet Two independent channels of streaming MPEG-4, H.264, or M-JPEG
CONTROL
Point To Point (stand alone) Standard
Ethernet Standard
Serial RS-232/-422; Pelco D, Bosch
Network Enabled Standard
GENERAL
Weight 9.5 lb (configuration dependent)
Dimensions (L,W,H) 18.1” × 5.5” × 6.3” (460 mm × 140 mm × 160 mm)
Power Requirements
Power Consumption
Inrush Current
24 VAC (21-30 VAC)
24 VDC (21-30 VDC)
24 VAC: 15 VA max no heater, 51 VA max w/heater
24 VDC: 10 W max no heater, 46 W
max w/heater
<5 A for DC power supply with slew rate > 10 ms
<19 A for AC power supply with slew rate > 4.17 ms
