Technical data22
22.19 FLIR GF309 24° Fixed lens
P/N: 44602-0102
Rev.: 45202
General description
The FLIR GF309 is an infrared camera for furnace and high temperature inspection (e.g., of industrial fur-
naces, chemical heaters, and coal-fired boilers), without the need to shut down the operation. The port-
able camera also greatly improves operator safety, by measuring through flames at a safe distance, for all
types of furnaces. A good knowledge of the furnace condition can avert failures and unscheduled
shutdowns
Industrial furnaces, heaters, and boilers are found in the chemical, petrochemical, and utility industries.
Benefits:
• Improved efficiency: The FLIR GF309 reduces inspection time by measuring the temperature through
flames without the need to interrupt the industrial process or await scheduled service shutdowns. A
furnace camera can help you to determine how to run a furnace/boiler efficiently to give the best fuel
economy and maximize production output and quality. As the FLIR GF309 has a wide temperature
range, high-accuracy electrical and mechanical inspections can be performed, which makes the cam-
era even more useful for predictive maintenance.
• The wireless connectivity of the camera allows you to connect to smart phones or tablets for the wire-
less transfer of images or the remote control of the camera—a useful function if regulations require a
second person to accompany the furnace inspector or thermal images needs to be sent quickly for a
second opinion.
• Increased worker safety: High-temperature measurement can be performed through flames in a non-
contact mode, and from a safe distance. Custom-built, the FLIR GF309 also features a detachable
heat-shield designed to reflect heat away from the camera and the camera operator, providing in-
creased protection. The camera is ergonomically designed, with a bright LCD and tiltable viewfinder,
which facilitates its use over a full working day.
• Increased furnace safety: Good knowledge of furnace/boiler condition and operating parameters can
provide the information needed to avert catastrophic failures and prevent unscheduled shutdowns.
Imaging and optical data
IR resolution 320 × 240 pixels
Thermal sensitivity/NETD <15 mK @ +30°C (+86°F)
Field of view (FOV)
24° × 18°
Minimum focus distance 0.3 m (1.0 ft.)
Focal length 23 mm (0.89 in.)
Lens identification Automatic
F-number 1.5
Focus Automatic (one touch) or manual (electric or on the
lens)
Zoom 1–8× continuous, digital zoom
Digital image enhancement Noise reduction filter
Detector data
Detector type
Focal plane array (FPA), cooled InSb
Spectral range
3.8–4.05 µm
Detector pitch 30 µm
Sensor cooling Stirling Microcooler (FLIR MC-3)
Electronics and data rate
Full frame rate 60 Hz
#T559157; r. AH/45951/45951; en-US
158
