4—Technical Data H-Series Operator’s Manual
30 March 2012
4–3 Environmental
4–4 Physical
4–5 Field of View
Ratings (not including the Hot Shoe
or the 2× Optical Extender)
IP-67, Submersible, 1 meter drop
Operational Temp. -4°F – 140°F (-20°C – 60°C)
HS-324
Weight (incl. lens) 1.59 lb. (721 g) with batteries; add 0.7 lb.
(315 g) for 2
× extender
Size (L
× W × H) 9.36” × 3.33” × 2.62”
(238
× 84.5 × 66.5 mm)
HS-307
Weight (incl. lens) 2.17 lb. (985 g) with batteries
Size (L
× W × H) 10.96” × 3.33” × 2.62”
(278.5
× 84.5 × 68.4 mm)
HS-324
Field of View (FoV)
24°
× 18°
FoV (w/Optional 2
× Extender) 12° × 9°
HS-307
FoV 7° × 5°
HS_Series_Operators.book Page 30 Thursday, March 29, 2012 3:03 PM
