H-Series Operator’s Manual 1—Introduction
431-0003-01-10, Revision 160 3
1–2 Detection Range
1
The illustration below shows the comparative range performance of
the H-Series camera with different lens configurations. The data is
based on detecting and recognizing a man 1.8 meters tall (and one-
half meter wide).
1. Actual range may vary depending on camera set-up,
environmental conditions, and user experience.
19 mm
Lens
19 mm
Lens with
2
×
Extender
65 mm
Lens
440 m Detection
110 m Recognition
720 m Detection
180 m Recognition
1.45 km Detection
370 m Recognition
HS_Series_Operators.book Page 3 Thursday, March 29, 2012 3:03 PM
