FLIR Lepton 1.6 - Page 10

FLIR LEPTON® Engineering Datasheet
The information contained herein does not contain technology as defined by the EAR, 15 CFR 772, is publicly available,
and therefore, not subject to EAR. NSR (6/14/2018).
Information on this page is subject to change without notice.
Lepton Engineering Datasheet, Document Number: 500-0659-00-09 Rev: 203
10
Output format
User-selectable 14-bit, 8-bit (AGC applied), or 24-bit RGB
(AGC and colorization applied)
Solar protection
Integral
Thermal radiometric
accuracy (Lepton 2.5 and 3.5)
- High gain mode: Greater of ±5 °C or 5% (typical)
- Low gain mode: Greater of ±10 °C or 10% (typical)
Electrical
Input clock
25-MHz nominal, CMOS IO Voltage Levels in accordance with
Electrical Specifications, page 73.
Video data interface
Video over SPI
Control port
CCI (I2C-like), CMOS IO Voltage Levels in accordance with
Electrical Specifications, page 73.
Input supply voltage
(nominal)
2.8 V, 1.2 V, 2.5 V to 3.1 V IO
Power dissipation
Nominally 150 mW at room temperature (operating), 5 mW
(standby). For 2.0, 2.5, 3.0 and 3.5 650mW during shutter
event.
Mechanical
Dimensions [mm] (w × l × h)
Lepton 1.5 (without shutter): 8.47 × 9.67 × 5.62
Lepton 1.6 (without shutter): 8.47 × 9.69 × 8.84
Lepton 2.0 (with shutter): 10.50 x 11.70 x 6.37
Lepton 2.5, 3.0, 3.5 (with shutter): 11.50 x 12.70 x 6.835
Dimensions with socket
105028-101 [mm] (w × l × h)
Lepton 1.5 (without shutter): 10.78 × 10.60 × 5.92
Lepton 1.6 (without shutter): 10.78 × 10.60 × 9.15
Lepton 2.0 (with shutter): 10.78 x 11.70 x 6.68
Lepton 2.5, 3.0, 3.5 (with shutter): 11.50 x 12.70 x 7.14
Weight (typical)
Lepton 1.5, 2.0: 0.68 grams
Lepton 2.5: 1.02 grams
Lepton 3.0, 3.5: 0.91 grams
Environmental
Camera operating
temperature range
Lepton 1.5, 1.6, 2.0, 2.5, 2.0, 3.5: -10 °C to +80 °C
Lepton 2.0, 3.0: Shutter operation limited to -10 °C to +65 °C
Non-operating temperature
range
-40 °C to +80 °C
Shock
1500 G @ 0.4 ms
