432-0003-00-28-en-US v110 Integration with Garmin Displays – Application Note
Supported FLIR Camera Models
 M-Series - M324XP
 M-Series - M625XP
 M-Series - M324L
 M-Series - M625L
 M-Series - M618CS
 M-Series - M612L
 MD-Series - MD324
 MD-Series - MD625
Note: FLIR M-Series cameras require the firmware package version 2.5.8 or newer. All M-Series
cameras shipped prior to September 2013 will require a firmware update. To determine the current
firmware version, refer to the Troubleshooting section below.
As described earlier, M-Series installations require the following Garmin accessory - Coupler, Marine
Network PoE Isolation P/N 010-10580-10.
If the M-Series has a single video connection (XP models), it is recommended the video cable from the
camera should be connected to the Video 1 port on the display. For M-Series cameras that have a
thermal imager and a visible (lowlight or color) camera, it is generally possible to connect both video
cables to the MFD and view both video images at the same time. However it will only be possible to
control the camera with one video channel. It is recommended the cable labeled “VIS/IR” should be
connected to the Video 1 port and used for control.
The FLIR MD-Series was released more recently than M-Series, and all cameras shipped to date have
the required version for compatibility with the Garmin display. It is recommended the video cable from
the camera should be connected to the Video 1 port on the display.
Firware updates and instructions are available from the online support site. Go to http://support.flir.com/
to download the latest version of firmware, or contact your local FLIR representative or call 877-773-
3547 inside the US.
Supported Garmin GPSMAP 8000 Series
 GPSMAP 8008
 GPSMAP 8012
 GPSMAP 8015
 GPSMAP 8208
 GPSMAP 8212
 GPSMAP 8215
 GPSMAP 8500 Black Box
 GPSMAP 8530 Black Box
Supported GPSMAP 8000 Series MFD’s will require software version 4.0 or newer. Refer to the user
documentation that comes with the display to determin the current software version.To update the
display, also refer to the user documentation, or refer to the Garmin web site:
http://www.garmin.com/support/software/marine.html
Garmin Marine Network Considerations
When connecting devices to the Garmin Marine Network, observe these considerations:
 A Garmin Marine Network cable must be used for all Garmin Marine Network connections
 Read the installation documenation that comes with the display and follow all recommendations
 Additional Garmin Marine Network cables and connectors are available from Garmin
