USER GUIDE 6
AUTOMATIC CALIBRATION
The camera has a mechanical shutter inside that periodically
activates and allows the thermal camera to do a calibration or
image refresh. When the shutter activates, the image will freeze
for a brief period. When the camera rst turns on, and periodically
thereafter, the app will perform an automatic calibration to
provide an optimal image. It is also possible to manually activate
the shutter by tapping the Calibration icon in the upper right on
the main screen. Calibration can be switched to manual by turning
o Automatic Calibration in the Settings Menu.
MSX ALIGNMENT CONTROL
The FLIR ONE Pro is tuned to align thermal and visual images
at a distance of 3 meters. To view scenes close-up, use the MSX
Distance slider control. Tap MSX Distance control to activate the
slider control, then adjust the alignment by sliding the control. To
exit the slider control, simply tap the icon again.
LOCK SPAN
The Lock Span function locks the temperature range of colors
in the display to the scene you are looking at. Simply tap the
Lock Span icon to hold the range, and tap it again to return to
auto-scaling of the scene.
SETTINGS MENU
The Settings Menu allows the user to congure additional features
on the FLIR ONE Pro, as described below.
SAVE LOCATION
If a mobile phone signal is available, the location will be added to
captured images. This makes it possible to see images on a map.
SAVE TO PHOTOS
Turn this on to save a copy of your images and videos in the
phone’s photo gallery. Images will always be stored in the FLIR ONE
Pro camera regardless of this setting. Items already captured will
not be copied.
TEMPERATURE UNIT
Use this setting to change the temperature unit of measure
between the Fahrenheit and Celsius scale.
MSX DISTANCE SLIDER
OFFSET
ALIGNED
